カラー鋼板屋根板

Core Advantages

Super Anti-Corrosion & Durability

Original three-pass passivation galvanizing process ensures strong galvanized layer adhesion; matched with high-weather-resistance fluorocarbon coating, it withstands 8000h salt spray and has an outdoor service life of over 25 years, far exceeding industry standards.

High-Precision Customization

Intelligent roll forming equipment with processing error ≤±0.3mm; customizable corrugation height 15-75mm and plate width 500-1200mm, adapting to purlin-free/purlin-mounted systems for large-span and special-shaped roofs.

Efficient Production Capacity

Annual output of 150,000 tons; flexible production line for both mass standard production and small-batch customization, with batch delivery by construction nodes to shorten project cycles.

Strict Quality Control

Full-process closed-loop quality management; multiple tests (tensile strength, coating adhesion, waterproof performance, etc.) from raw material procurement to ex-factory; weld fatigue life over 3 million cycles with excellent structural stability.

Full-Cycle One-Stop Service

One-stop solutions including roof system design, profile customization, installation guidance and after-sales maintenance; industrial chain synergy to meet diversified needs of industrial, municipal and commercial projects, with quality recognized by benchmark projects.

We specialize in manufacturing high-quality color steel roofing sheets, selecting premium Q195/Q235 low carbon steel as the base plate raw material, which are exquisitely processed through surface degreasing and phosphating, high-precision roll coating and baking, intelligent roll forming as well as multiple quality inspection processes. Our products feature strong coating adhesion, high profile precision and excellent structural stability, with a complete range of specifications for all series of profiles including concealed clip, corrugated and sandwich types. Customized processing of plate thickness, effective width, coating type and length is available on demand. Contact us now for the latest quotation of color steel roofing sheets, free sample application and professional roof system supporting solutions — global export business is supported!

Technical Specifications

Application Fields & Typical Cases

Industrial Construction

Core Applications: Large production plants, heavy industry workshops, storage warehouses, cold chain storage roofs.

Typical Case: East China Auto Parts Intelligent Production Base adopted Concealed Clip Ⅲ 820 sheets (PVDF+Q235, 0.6mm thickness) for 15,000㎡ roof. It resists level 12 typhoons and acid-base waste gas corrosion, with no rust/leakage after 6 years; weld fatigue life 1.5 million cycles (40% higher than traditional sheets), reducing roof weight by 800 tons.

Public Construction

Core Applications: School, hospital, bus hub and other public building roofs.

Typical Case: Southwest Experimental Middle School new campus used hidden fastener sandwich sheets (rock wool core) for 8,000㎡ roof. It maintains 65% yield strength at 600℃, 3-hour fire resistance limit with 1.5mm fire coating, 35dB sound insulation; project cycle shortened by 1 month.

Agricultural & Temporary Construction

Core Applications: Greenhouses, breeding sheds, construction site temporary buildings, post-disaster resettlement house roofs.

Typical Case: North China Ecological Agriculture Base selected HDP coating sheets (0.5mm thickness) for 10,000㎡ roof. It resists ammonia/water vapor erosion, 1500h salt spray test, no coating peeling after 4 years; 90% recovery rate for disassembly and reuse (50% lower secondary cost). 3,000㎡ roof completed in 7 days for a high-speed rail temporary project.

Our Industrial Advantages

Shunchen Industry has nearly 20 years of technical accumulation in color steel roofing sheet manufacturing, focusing on coating technology and profile design. It integrates 8 core processes (cold rolling, roll coating, etc.) with original double-sided coating three-pass curing technology to form a standardized production system. Products reach 0-grade coating adhesion, with weather resistance far exceeding GB/T12754-2019. Customizable profile and coating schemes for different scenarios, leading in both quality and cost performance.

FAQs

Q1: What factors should be considered when selecting the coating type of color steel roofing sheets?

A: For indoor/dry inland areas, PE coating is cost-effective; for coastal high-salt-spray or outdoor long-term use scenarios, PVDF coating is recommended; for agricultural greenhouses with harsh environments, HDP coating is the optimal choice.

Q2: Can the color steel roofing sheet be customized with special colors and logos?

A: Yes, we support customized roll-coating of special colors according to RAL/Pantone color cards, and can also print project logos or anti-counterfeiting marks on the sheet surface as required.

Q3: What is the delivery time for customized color steel roofing sheet orders?

A: For standard specification orders, the delivery time is 3-5 working days; for small-batch customized profiles/coatings, it is 7-10 working days; for large-scale project orders, we will confirm the delivery schedule according to the construction node and production capacity.

Q4: Do you provide on-site installation guidance and after-sales maintenance services?

A: Yes, we have a professional technical service team to provide on-site installation guidance and construction technology training. We also provide a long-term after-sales maintenance service, and respond to quality problems within 24 hours for on-site handling.

Q5: What is the MOQ for color steel roofing sheet orders, and do you support sample provision?

A: There is no strict MOQ; we support small-batch trial orders for project testing. Free samples (within 1 square meter) can be provided, and the customer only needs to bear the freight cost.
